SZM 越野叉车
类别：SZM 越野叉车 作者：guanli 日期：2014/1/23 16:06:16
|
参数Parameters | ||
|
速度Speed |
行驶速度Driving speed |
25km/h |
|
起升速度Lifting speed |
300mm/s | |
|
举升速度Lifting height |
400mm | |
|
##爬坡度Max.ground ability |
20% | |
|
整机重量Operaitng weight |
6750Kg | |
|
轮胎Tyre |
前轮Front wheel |
11.00R-20 |
|
后轮Rear wheel |
16/70-20 | |
|
轮距Wheel tread |
1700 | |
|
轴距Wheel base |
2350 | |
|
##小离地间隙Min. Ground clearance |
300mm | |
|
蓄电池Battery |
24V | |
|
发动机Engine |
玉柴 YCDJ12T-85 | |
|
发动机功率Engine power |
62kw/2400rpm | |
|
外形尺寸Overall dimension |
5750*2200*3050 | |
|
概况Oberview | ||
|
动力形式Power mode |
柴油Diesel | |
|
额定载荷Rated load |
5500kg | |
|
载荷中心距Load centor distance |
500mm | |
